high quality outside and inside usages wall printing machine
vertical 2years warranty
The wall painter adopts advanced multi-axis motion full computer
control system, Powerpc processor, 1EEE12844 two-way ECP parallel
port transmission interface, EN-RTC, HP-RTC, HP/GL-2 language mode,
windows95/98/XP computer output Program, no template, direct
printing, bright color, lifelike as color photo level
Using computer-controlled multi-axis inkjet printer, the mineral
pigment ink used in the construction
process will not produce any peculiar smell and is waterproof and
sunscreen not easy to fade.
Patterns
The patterns are colorful and lifelike, and the degree of fidelity
exceeds that of hand-painted,
and the colors are durable and performance, which meets the
aesthetic requirements of current cultural decoration.
The wall painter can be used for flat equipment such as ceramic
tiles, wood panels, acrylic, PVC, metal plates,
glass, etc., as well as all kinds of walls with adhesion.The wall painting machine uses special environmentally
friendly organic water-based ink, the color is full and fresh,
durable and waterproof
The detailed parameter as follows.
| Modle Type | SSV-2 | |
| Ink base color | Double four colors , water-based INK | |
| Paint direction | Vertical | |
| Jet distance | 0.5-1CM | |
| Motherboard | 8-core high-speed CPU, 4GB RAM, Hi-Speed USB I/O port | |
| Nozzle type | EPSON, Japan Epson nozzle*2 |
| Motor | Three Intelligent motor +Reducer |
| Wall detection | Two Nano detector |
| Power down alarm | Real-time power failure alarm system |
| UPS power | Super uninterruptible power supply, Power outage 3hours |
| Ink supply system | Four-color ink cartridge integrated, 400 ml large-capacity ink
cartridge negative pressure system for special color, with sealing
plug and dust cover |
| Motor technology | Brushless motor, vector positioning system. No need for grating
bars to be affected by light |
Print material
| Suitable for users inside and outside putty wall, large white,
imitation porcelain wall, latex paint wall, inkjet cloth, wall
clothing, color glaze, color paint wall, etc.Tile, glass, acrylic,
wood, pvc and metal materials ( Add layer) |
| Print resolution | 360*720dpi / 720*1080dpi / 720*1440dip / 1080*1440dpi /
1440*2880dpi |
| Support image format | PSD/CDR/JPG/JPGE/PNG/BMP/TIFF/AI/PDFAnd other image formats. Some
formats need to be converted |
| Ink consumption/㎡ | 10-20ML, depends on the quality of the pictures you want to print |
| Print size | 2m height with any width, the machine is equipped with a laser
positioning system, and large pictures over height 2 meters can be
seamlessly stitched and printed. |
| Power supply | AC110V(90-132V) / AC220V(180-264V) AC,47-63HZ |
| Noise | Standby less than 15dba, work 50dba |
| Model type: | WPM-S3 |
| Machine body | Aluminum magnesium ,alloy profiles, frame structure |
| Assemble way | movable wheels and slide railway and rapid assemblely |
| Operation | Automatically controlled by computer |
| printhead | epson industrial nozzles x3pcs |
| ink type: | specialized water-base ink for wall printer |
| printing speed | fast | Mode | Speed | | |
| medium | sketch mode | 24㎡/h | |
| slow | produce mode | 18㎡/h | |
| three speed | quality mode | 12㎡/h | |
| | Fine mode | 9㎡/h | |
| suppying system | negative pressure,400ml ink tank,colors in one unit |
| Technology | VSDT Variable ink drop technique feature technology |
| photo format | support PNG/JPG/TIFF/PDF/PSD/AI AND CDR.ETC |
| Precision | 720x720 DPI/720X1080DPI/720X1440DPI/720X2280DPI |
| Print size | No limite |
| Power supply | AC 110V /220V Frequancy:50hz/60hz |
| power consumption | no load 20w ,load 120w |
| Noise | standby <20DBA ,Working <50DBA |
| Storage | —30 -+60℃ |
| operation | ,-10-+50℃ |
| operation system | window ,xp/ win 7/win8 ,win 10 |
| language | English and chinese |
Our machine can be used outside and inside .The pictures can be
very clearly. Hope you love our effect!
