Aluminum magnesium alloy profiles frame s direct wall inkjet
printer for outdoor and indoor wall usage 2years warranty
We have a creative team with young and middle-aged as the main
force. The painters have more than 5 years of mural painting
experience, and they have a solid foundation and strive to achieve
customer satisfaction.
The company also has a professional design team to provide you with
professional hand-painted wall pattern design and production. It
can also design and paint on-site according to your requirements,
and pay regular visits.
After years of development and innovation, with profound artistic
skills and painting experience, we are committed to creating a
fashionable and beautiful art space with unremitting efforts and
continuous progress. We sincerely wish to communicate closely with
customers, with the fullest enthusiasm and the best service.
The detailed parameter as follows.
| Double nozzle wall painting machine specification |
| Model type: | WPM-S2 | |
| Machine body | Aluminum magnesium ,alloy profiles, frame structure |
| Assemble way | movable wheels and slide railway and rapid assemblely |
| Operation | Automatically controlled by computer |
| printhead | epson industrial nozzles x2pcs |
| ink type: | specialized water-base ink for wall printer |
| Painting speed | | mode | speed |
| high speed | Sketch mode | 30sqm/h |
| Medium speed | Production mode | 20sqm/h |
| Low speed | Quality model | 14sqm/h |
| Three levels adjustable | Fine mode | 10sqm/h |
| Ink supply system | Negative pressure ink supply, 500ml pigment library, special supply
for spot colors, with sealing plug and dust cover |
| Painting technology | Adopt VSDT variable ink drop technology, high fault-tolerant
feathering technology, automatic recovery printing technology |
| Image Format | Supports PNG, JPG, BMP, TIFF, PDF, PSD, Al and CDR etc. |
| Painting accuracy | 720*720DPL 720*1440DPL 1440*1440DPL 1440*2880DPI painting size |
| Picture height | 2 meters, the width can be extended arbitrarily |
| power supply | AC110V/AC220V. AC 50HZ mains and household electricity |
| Power consumption | No load 20W, working 120W |
| Noise situation | Standby <20DBA, working V50DBA |
| Storage environment | ,-30°C-60°C, 10%-80% relative humidity, non-condensing |
| Operating environment | ,-10°C-60°C, 10%-80% relative humidity, non-condensing |
| operation system | window ,xp/ win 7/win8 ,win 10 |
| language | English and chinese |
RFQ
1. What is the cost of printing one square meter of consumables?
The printing accuracy and quality requirements are different, and
the amount of ink required is very different.
The industry generally uses an algorithm that consumes 12-15ml of
ink per square meter of ink,
so the cost of a full-spray consumable is about 3 yuan, and the
cost of light or sub-printing is lower.
2. Assist customers in determining system configuration and
providing investment solutions.
3. Provide customers with suggestions for site layout of each
system to ensure
Smooth installation is in place.
4. Arrange the equipment master to carry out a full set of software
and hardware training.
