400ml ink 120w TX800 Piezoelectric Inkjet Wall Printer

    Buy cheap 400ml ink 120w TX800 Piezoelectric Inkjet Wall Printer from wholesalers

    Buy cheap 400ml ink 120w TX800 Piezoelectric Inkjet Wall Printer from wholesalers
    • Buy cheap 400ml ink 120w TX800 Piezoelectric Inkjet Wall Printer from wholesalers
    • Buy cheap 400ml ink 120w TX800 Piezoelectric Inkjet Wall Printer from wholesalers

    400ml ink 120w TX800 Piezoelectric Inkjet Wall Printer

    Ask Lasest Price
    Brand Name : shervin
    Model Number : WPM--S3
    Certification : CCC.CE.ROHS
    Price : Price can be negotiable
    Payment Terms : T/T, Western Union, L/C, D/A, D/P, MoneyGram
    Supply Ability : 2000 sets/month
    Delivery Time : within 5days after your payment
    • Product Details
    • Company Profile

    400ml ink 120w TX800 Piezoelectric Inkjet Wall Printer

    High speed silent track TX800 Micro piezoelectric ink-jet technology Wall mural printing Machine with 3 years warranty


    Quick details


    1,the ink of 3D vertical wall printing machine using imported paste, no heating, minus 10 ºC to zero 60 ºC in the normal work environment, no ice, continuous ink, colorful, three-dimensional sense of strong, do not fade, can not afford skin, three-dimensional sense of strong Scrub, green.

    2.Sprinkler data signal using optical fiber integrated output.Faster, anti-interference ability, high reliability, stable transmission data.

    3.Automatic fill system.Construction accidentally interrupted, fill the system can effectively reduce the painting scrap rate.

    4.Fuselage reserved UPS, inverter interface (can be installed built-in power supply system, the3D vertical wall printing machine power off for about 10 hours).


    5.Advanced AC servo control technology to ensure higher precision printing, better stability and longer service life.


    The detailed parameter as follows.


    Modle TypeSSV-2
    Ink base colorDouble four colors , water-based INK
    Paint directionVertical
    Jet distance0.5-1CM
    Motherboard8-core high-speed CPU, 4GB RAM, Hi-Speed USB I/O port
    Nozzle typeEPSON, Japan Epson nozzle*2
    MotorThree Intelligent motor +Reducer
    Wall detectionTwo Nano detector
    Power down alarmReal-time power failure alarm system
    UPS powerSuper uninterruptible power supply, Power outage 3hours
    Ink supply systemFour-color ink cartridge integrated, 400ml large-capacity ink cartridge negative pressure system for special color, with sealing plug and dust cover
    Motor technologyBrushless motor, vector positioning system. No need for grating bars to be affected by light

    Print material

    Suitable for users inside and outside putty wall, large white, imitation porcelain wall, latex paint wall, inkjet cloth, wall clothing, color glaze, color paint wall, etc.Tile, glass, acrylic, wood, pvc and metal materials ( Add layer)
    Print resolution360*720dpi / 720*1080dpi / 720*1440dip / 1080*1440dpi / 1440*2880dpi
    Support image formatPSD/CDR/JPG/JPGE/PNG/BMP/TIFF/AI/PDFAnd other image formats. Some formats need to be converted
    Ink consumption/㎡10-20ML, depends on the quality of the pictures you want to print
    Print size2m height with any width, the machine is equipped with a laser positioning system, and large pictures over height 2 meters can be seamlessly stitched and printed.
    Power supplyAC110V(90-132V) / AC220V(180-264V) AC,47-63HZ
    NoiseStandby less than 15dba, work 50dba

    printing speedfastModeSpeed
    mediumsketch mode24㎡/h
    slowproduce mode18㎡/h
    three speedquality mode12㎡/h
     Fine mode9㎡/h
    suppying systemnegative pressure,400ml ink tank,colors in one unit
    TechnologyVSDT Variable ink drop technique feature technology
    photo formatsupport PNG/JPG/TIFF/PDF/PSD/AI AND CDR.ETC
    Precision720x720 DPI/720X1080DPI/720X1440DPI/720X2280DPI
    Print sizeNo limite
    Power supplyAC 110V /220V Frequancy:50hz/60hz
    power consumptionno load 20w ,load 120w
    Noisestandby <20DBA ,Working <50DBA
    Storage—30 -+60℃
    operation,-10-+50℃
    operation systemwindow ,xp/ win 7/win8 ,win 10
    language

    English and chinese



    1. New Technology, New Business Opportunity.
    2.two year warranty, Lifetime technical support.
    3. Environmental, low-cost, individually wall decoration.
    4. Wide applications: It prints the picture (designs) on any wall, applying to the decoration of family, hotel, bar, kindergarten, school and the Government propaganda etc.
    5. Perfect performance: the full color image complete at once; fast dry; the vivid image is waterproof, sun-proof and wear resistance.
    6. Easy-to-Operate: totally automatic, Everyone can master all of skills within 1 or 2 days. No need of any professional knowledge.
    7. Including standard accessories and the computer (the software is installed), ready come to work.



    Quality 400ml ink 120w TX800 Piezoelectric Inkjet Wall Printer for sale
