    1/16scan 5500cd P15 Semi Outdoor LED Grid Screen

    Ask Lasest Price
    Brand Name : shervin
    Model Number : SST-P15
    Certification : CCC.CE.ROHS
    Price : 900usd-1500 usd /sqm
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 5000sqm per month
    Delivery Time : within 5days after your payment
    • Product Details
    • Company Profile

    1/16scan 5500cd P15 Semi Outdoor LED Grid Screen

    new style high brightness and less weight super thin semi outdoor led grid screen for outdoor fixed usage


    LED grid screen refers to a kind of LED display that is made up of grid-shaped light bars in the current industry, and it is also another name for light bar screens. Because its form is hollow and grid format, people in the industry call it grid screen, hollow screen, etc.


    LED grille displays are mainly used in outdoor walls, glass curtain walls, and building tops, as well as outdoor three-sided flip-flops, column billboards, LED curtain walls, etc. The cross-age design of the LED grid screen breaks through the many limitations of the traditional LED display on the building and wall, making the project more flexible and more selective.


    The K speed is widely used in various fields. Now let Maipu Guangcai editor take you to understand the advantages of LED grid screen technology and how it brings various conveniences to the project.


    Due to the special structure of the product, it is different from the previous box-type LED display. Maipu's brilliant LED grid screen has the following five technical characteristics:

    1. Light weight and low wind load.

    2. High efficiency and low power consumption.

    3. IP67 high protection level.

    4. Highly integrated, energy-saving, the power per square meter is as low as 80W/square meter

    5. Easy to install without steel structure installation, no air conditioning, can be installed front or rear The LED grid screen is light in weight and the wind load is small. For the LED grid screen, light weight is our most direct real experience. Maipu's glorious LED grid screen, the weight is due to the screen body grid, which allows the LED display to permeate the wind, so its wind load capacity is extremely strong


    The detailed specification as follows.


    Itemunitparameter
    Product number CP7.8-12S
    Pixel pitchmmHorizontal 12.5 Vertical 7.8125
    Pixel compositionDIPSMD2727
    Resolutiondot/㎡10240
    Cabinet sizemm500(W)X1000(H)
    Cabinet resolutiondot5120
    Cabinet resolutiodot40(W)X128(H)
    Cabinet weightkg/pcs9.5
    One sqm weightkg/㎡19
    Cabienet thickcm6.3
    Installation thicknesscm12.3
    Peak power consumptionW/㎡800
    AverageW/㎡240
    Screen brightnesscd/㎡≥7000cd
    Gray scalebit14
    Color temperatureK6500-9300k
    Brightness adjustmentLossless grayscale0-255level
    Viewing angle°Horizontal ≥120° Vertical ≥120°
    Best viewing distancem10-200
    Frame rateHz60
    way to control Synchronous control or asynchronous control
    Drive way Constant current static
    Supply voltageAC V85-250
    Design life =100,000 hours
    Cooling method Structure-enhanced natural convection
    Light bar widthmm8.8
    Light bar material 6061 stretched aluminum
    Hollow rate%30%
    Protection levelIPDouble-sided overallIP66
    Working temperature/Storage temperature°C-35 ~ + 80°C / -55 ~ + 120°C
    Frame material 2.0mm cold rolled galvanized steel sheet
    Installation form Tool-free quick installation
    Fire performance Full V0 flame retardant
    Maintenance speed 10S/unit
    Maintenance method front back


    We also offer 3% of spare parts. Like modules, power supplies, cables, power cords, screws, etc. Make sure you can use it 100% safely.

    Without any concern, choosing us as your supplier is to choose our long-term friendship. If you encounter any problems,we will do our best to help you solve them.


    the grid feature as follows.


    1. The cabinet is super light, super thin and super transparent
    For LED grid screens, light weight is a major advantage. The LED grille screen adopts the outer frame all-aluminum profile design, which is ultra-thin and light. The unit thickness is only 84mm and the weight is only 13kg/㎡. Its hollow structure design enables the LED grille screen to transmit light and wind, and has strong resistance to wind pressure ability.
    2. High brightness, energy saving, easy maintenance
    The brightness of the ATO series outdoor LED grille screen can exceed 10000cd/㎡. It uses high-efficiency, high-brightness, high-quality LED lights, high conversion efficiency power supply, and average power consumption per hour about 150W/㎡. The product naturally dissipates heat without air conditioning. Heat dissipation, green and energy saving. The product has a light structure, quick installation, and front/rear maintenance, which is very convenient.
    2. The cabinet is designed with high protection and can be customized
    The LED grid screen unit realizes the waterproof grade IP65, waterproof, dustproof, fireproof, low temperature, high temperature, lightning, and corrosion protection. The cabinet can be customized in a variety of shapes such as arcs and cylinders to meet the diverse needs of owners and designers.
