SMD3535 Nationstar led lamp Meanwell power supply water-proof
cabinet outdoor fixed led display.
Specifications:
Indoor Outdoor LED Screen (Part of it, contact in detail)
Outdoor led module display panel p3 p4 p5 p6 p6.25 p8 p10 p16 led
wall window screen
p3 p4 p5 p6 p6.25 p8 p10 p16 outdoor fixed ultra slim led screen
for building, factory, stadium, restaurant, publicity, street .…
With high refresh rate, high brightness, and fast assembling.
With waterproof, light & thin, and good heat dissipation.
Warranty for 5 years . no dead lamp and long time working hours .
The detailed parameters as follows.pls check it
Pixel Pitch | 10mm | Type | SMD3535 |
Chip parameters | Red λd:(620-625nm) IV:(800-960mcd) | Chip parameters | Green λd:(520-525nm) IV:(1350-1650mcd) |
Chip parameters | Blue λd:(470-475nm) IV:(330-400mcd) | Module Resolution | 32×16=512(Dots) |
Module Size | 320×160mm | Pixel Density | 10000 Dots/㎡ |
Cabinet Resolution | 96×96=9216(Dots) | Cabinet Dimension(W*H*D) | 960×960×130mm |
Cabinets Material | Steel | Cabinet Weight | 39kg |
Brightness | ≥7500cd/㎡ | Viewing Angle | 120(Horizontal),120(Vertical) |
Nearest Viewing Distance | 13m | Power Consumption (Max) | 1000 w/㎡ |
Power Consumption (Average) | 300 w/㎡ | Refresh Rate | ≥1000Hz |
Input Voltage | AC110-220V±10%,50/60Hz | Grey Scale Levels | 16bit |
Brightness Adjustment | 256 color levels,can be adjusted manually and automatically
optional | Life-span | 100,000 hours |
Protection Level(front/back) | IP66/IP54 | Working Temperature | -30℃~50℃ |
Humidity | 15%~85% | Drive Mode/Driver Position | Constant driving 1/2 Scan,Combined diver board |
Input Signal | AVI/MPG/MPEG/TXT.etc | Control Mode | Synchronization/Asynchronization |
Certificate Control System | CE,ROHS,FCC,ISO9001,TUV Sending Card, Receiving Card,Receiving HUB | PC Operating System | Microsoft Windows 7, XP and Vista |
CSoftware | LED Studio ( MIKE_TV-linsn ) | Certificate | CE,ROHS,FCC,ISO9001,TUV |
Communication Type | Net cable,3G,WIFI(Sold separately) | Control Card Input | DVI,USB,RJ45,HDMI(Sold separately) |
Language | English,French,Japanese,Russian,Thai,Spanish,Polish,Italian,Portuguese,Turkish,Dutch,Greek,Bulgarian,Romanian,Arabic |
Q1. Are you a factory or trading company?
A:We are a factory.
Q2. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q3. What about the lead time?
A:Our products could be shipped by Sea, by Air or by Express. Which
method to be used is based on the weight and size of the package
and with consideration of customer's requirements.
By sea: 10-30 days;By air: 5-10 days ; By express: 3-6days.
Q4. What's the shipping way, shipping time?
A:Our products could be shipped by Sea, by Air or by Express. Which
method to be used is based on the weight and size of the package
and with consideration of customer's requirements.
By sea: 10-30 days;By air: 5-10 days ; By express: 3-6days.
Q5. How to proceed an order for led light?
A: Please send us your purchase order by Email, Fax, Skype, Whats
App, Facebook or making a call, and we will send you PI as your
approval. Please let us know the following information for your
order.
1) Product information: Quantity, Specification (Item , logo and
Packing requirement)
2) Delivery time required
3) Shipping information: Company name, Detailed shipping address
with zip code and Phone number.
