Automatic lifting high speed silent track wall mural printer for outdoor and indoor usage 3 years warranty
1. The operation steps of wall painting machine
1. Choose a pattern
Choose the pattern to be drawn according to your hobby and
decoration style.
2. Wall adjustment
Pay attention to the shortcomings of the wall. If the wall is not
flat, it is recommended to adjust it. If the unevenness of less
than 2cm has little effect on the wall painter, if it exceeds, it
will easily leave flow marks on the wall, so be careful before
drawing.
3. Prepare for drawing
First of all, adjust the nozzle. If the machine has not been used
for a long time, squeeze out the ink that has been stored at the
nozzle first to avoid clogging the nozzle and affecting the drawing
effect. After adjusting the machine, import the pattern that needs
to be drawn and print immediately.
2. What is the effect of the wall painting machine?
1. It is widely used. Any picture and a relatively flat wall can
make a better wall painting (the clarity of the picture affects the
final presentation effect).
2. The disadvantage of the wall painter is that it cannot show the
charm that a painter can produce.
3. The wall painting machine has certain requirements on the wall.
If the wall surface is more than 2cm uneven, the nozzle will be
damaged and the wall will be stained with ink, which will affect
the drawing progress.
The detailed parameter as follows.
Model type: | WPM-S3 | ||||||||
Machine body | Aluminum magnesium ,alloy profiles, frame structure | ||||||||
Assemble way | movable wheels and slide railway and rapid assemblely | ||||||||
Operation | Automatically controlled by computer | ||||||||
printhead | epson industrial nozzles x3pcs | ||||||||
ink type: | specialized water-base ink for wall printer | ||||||||
printing speed | fast | Mode | Speed | ||||||
medium | sketch mode | 24㎡/h | |||||||
slow | produce mode | 18㎡/h | |||||||
three speed | quality mode | 12㎡/h | |||||||
Fine mode | 9㎡/h | ||||||||
suppying system | negative pressure,400ml ink tank,colors in one unit | ||||||||
Technology | VSDT Variable ink drop technique feature technology | ||||||||
photo format | support PNG/JPG/TIFF/PDF/PSD/AI AND CDR.ETC | ||||||||
Precision | 720x720 DPI/720X1080DPI/720X1440DPI/720X2280DPI | ||||||||
Print size | No limite | ||||||||
Power supply | AC 110V /220V Frequancy:50hz/60hz | ||||||||
power consumption | no load 20w ,load 120w | ||||||||
Noise | standby <20DBA ,Working <50DBA | ||||||||
Storage | —30 -+60℃ | ||||||||
operation | ,-10-+50℃ | ||||||||
operation system | window ,xp/ win 7/win8 ,win 10 | ||||||||
language | English and chinese |
The so-called painting must be decorative. The wall is like paper.
Through design, creation and painting, the wall is rich and full.
Even simple lines can bring good decorative effects.
Without appreciation, there is no painting. The children's room at
home is decorated with murals, which can stimulate children's
imagination through unique appreciation, that is, enhance
children's ability to observe colors.
1. Environmental protection
There are many decorative materials for home improvement walls,
such as latex paint, wallpaper, wall coverings, etc. The use of
these materials to decorate walls will contain formaldehyde, which
will pollute the room. In contrast, the special environmentally
friendly organic water-based ink used by Hezhong's intelligent wall
painter is more environmentally friendly. Therefore, the owner who
uses the wall painting mechanism diagram does not have to bear the
hazard of heart formaldehyde.
2. Convenient construction
Take the smart wall painter as a reference. No painting skills are
needed. Just fix the position. After the size is determined, import
the picture into the computer and it can be printed immediately.
The fastest is 24 square meters per hour. When you need to change
the pattern, you only need to paint again. White paint covers the
pattern and can be reprinted.
The wall painting machine can be used for most wall surfaces, such
as: putty walls for internal and external walls, latex paint walls,
large white, imitation porcelain walls, rice paper, canvas, wall
clothing, colored glaze, shell powder, color grain paint Wait for
walls, etc.; you can also operate on glass, ceramic tiles, wood,
acrylic, PVC, and metal plates, but you only need to go through the
layers before printing.
![]() |
